POLYCARBONATE AWNING

FEATURES

These awnings are assembled using baked paint aluminium extrusions that never rust. Made to measure to cover windows, doors, patios, decks and carports.

  • Awnings with a projection of less than 84˝ are installed with regular rafter-braces. Awnings with a projection of 84˝ or more are installed using heavy duty beams.
  • A bridge-beam (aluminium angle 2˝ x 3˝ x ¼˝) is required when the distance between the posts is greater than 60˝ and can be used up to a maximum span of 144˝.
  • Our special wall flashing makes installation easier.

ALUMINIUM FRAME & BRACKETS

POLYCARBONATE

ALUMINIUM BRACKETS FOR AWNING

HD Brackets can be used for awnings with a projection of up to 42″.

OPTIONS
  1. Aluminium gutter
  2. Aluminium snow guard
REFER TO THE CATALOG FOR MORE DETAILS ON THIS PRODUCT
DETAILS
  1. Aluminium wall flashing
  2. Aluminium standard flashing
  3. Aluminium “U” runner
  4. Aluminium rafters (A = standard, B = “HD”)
  5. Special aluminium “C” runner
  6. Aluminium “C” runner
  7. Aluminium support columns
  8. Mechanical anchor @ 16˝ c/c
  9. Aluminium ornaments (A = “Ultra”, B = “S”)
  10. Polycarbonate “Suntuf” runner
  11. *Optional: aluminium “L” bridge 3˝ x 2˝ x ¼˝
